ignition transformer
ignition transformer
high-voltage ignition transformers are widely used in the ignition of kitchen equipment burners, small burners, fuel gas, tunnel kiln burners, integrated burners, radiation tube burners, high-speed burners, industrial furnaces.
Input | Voltage： 220V/50Hz | Voltage： 220V/50Hz | Voltage： 220V/50Hz | Voltage： 220V/50Hz | DC 24V |
Current：≤0.7A | Current：≤1. 1A | Current：≤1.2A | Current：≤1.8A | Continuousignition0.4~0.5A. Gapignition0.8~12A | |
Output | Voltage：≥1×6kV | Voltage：≥1×8kV | Voltage：≥2×5kV | Voltage：≥2×7kV | ≥15kV |
Current：≥15mA | Current：≥20mA | Current：≥20mA | Current：≥25mA | ||
Boundary dimension | 82×69×67mm | 100×92×73mm | 100×92×73mm | 100×92×73mm | 95×80×62mm |
Ignition distance | 2~3mm | 3~5mm | 3～5mm | 4～6mm | 3~5mm |
Ignition in 3 minutes, efficient | Gap：33% | Gap：33% | Gap：33% | Gap：25% | Gap：33% 、100% |
Continuous： --- | Continuous：100% | Continuous：100% | Continuous：-- | Continuous：-- | |
Output type | Monopole, double pole | Monopole, double pole | Double pole | Double pole | |
Output form | Down-lead,plug- in | Down-lead,plug- in | Down-lead,plug- in | Down-lead,plug- in | |
Output form | Ignition of kitchen equipment burner, small burner, fuel gas, tunnel kiln burner, radiation tube burner, high-speed burner | Ignition of combustion devices like integrated combustion machine, irradiated alkane burner, high-burner nozzle, C furnace | Ignition of combustion devices like integrated burner, radiation tube burner, high-speed burner, industrial furnace | Ignition of combustion devices like integrated burner, radiation tube burner, high-speed Yuanjiao T industry furnace | Ignition of combustion devices like integrated burner, radiation tube radiation tube burners, high-speed burners, industrial furnaces |
